Used Sany Truck Crane Zoomlion STC 75 Ton Second Hand Crane
Production Details:
| Model NO. | SYM5462JQZ | Boom Type | Telescopic |
| Max. Rated Lifting Capacity | 75000 kg | Max. Lifting Height of Jib | 45m |
| Max. Gradeability | 40% | Turning Diameter | 23m |
| Transport Package | Compliant with export packaging requirements | Specification | 14000×2750×3700mm |
| Drive Mileage | 38381.4kms | Working hours | 12088.5h |
| Trademark | Sany | Origin | China |
The maximum rated lifting capacity is 75T, and the minimum working range is 3.0m. Five-section booms, partially synchronous telescopic boom, the full extension of the main boom is 45m, and the maximum lifting height of the main boom is 45m.
The maximum rated power of the engine is 276KW, European Ⅲ standard. The maximum speed can reach 80km/h, and the maximum climbing ability is 40% (theoretical). The lifting capacity of the main boom working range adopts SANY SYML moment limiter to provide customers with safe and effective protection. Adopts the load sensing and constant power control hydraulic system independently developed by SANY.
The vehicle's exhaust emissions comply with the European Stage 3 emission standards (Euro III), and its safety devices meet the requirements of CCC certification.
This Truck Crane was produced in 2011, drived more than 38381.4kms, and worked more than 12,088.5 hours, with a weight of 75T, Weichai WP12 engine, no big repairs, no malfunction, regular maintenance, excellent performance at present, equipped with 70T hook, five-section boom, jib 18.5 meters, with a counterweight of 12 tons.
Product Parameters:
| Project | Value | Remark |
| Working performance | Max. Rated Gross Lifting Weight (kg) | 75000 | |
| Max. load moment of the basic boom (kN.m) | 2400 | |
| Max. load moment of the longest main boom (kN.m) | 318 | |
| Basic boom Max. lift height (m) | 12 | |
| Main boom Max. lift height (m) | 45 | Boom deformation is not considered |
| Max. lifting height of jib (m) | 15.7 |
| Working Speeds | Max. hoist rope speed (main winch) (m/min) | 130 | Reel fourth layer |
| Max. hoist rope speed (auxiliary winch) (m/min) | 139 | At second layer |
| Boom derricking up time (s) | 120 | |
| Boom telescoping out time (s) | 80 | |
| Max. rotation speed (r/min) | 2.4 | |
| Traveling Parameter | Top speed (km/h) | 80 | |
| Max. gradeability (%) | 40 | |
| Min. turning diameter (m) | 23 | |
| Min. ground clearance (mm) | 290 | |
| Limits for exhaust pollutants and smoke | Conform to related standards | GB3847-2005 GB17691 -2005 The third phase |
| Fuel consumption/100 km (L) | 45 | |
| Weights | Deadweight in traveling condition (kg) | 45000 | |
| Complete vehicle kerb mass (kg) | 45870 | |
| Front axle load (kg) | 19000 | |
| Rear axle load (kg) | 26000 | |
| Dimensions | Dimensions (L×W×H) (mm) | 14000×2750×3700 | |
| Longitudinal distance of outriggers (m) | 7.6 | |
| Outrigger lateral distance (m) | 6.1 | |
| Main boom length (m) | 45 | |
| Main boom elevation (°) | -2～80 | |
| Jib length (m) | 10.8 ,18.5 | |
| Offset (°) | 0 ,15, 30 | |
| Chassis | Model | stc75 |
| Type | Ⅱ |
| Engine | Model | WP10.375N |
| Rated power (kW/r/min) | 276/2200 |
| Max. output torque (N.m/r/min) | 1460/1100~1400 |
| Manufacturer | Sany |
